The 3M Scotchlok Connectors 20000 Series can be used with either copper or aluminum conductors. These aluminum connectors feature color coded end caps for identification. Contact aid provided in connector is compatible with poly/EPR insulations. Each connector is electro tin plated to resist electrolytic corrosion, and have a solid center stop. (UL 486B Listed)
For more information about Scotchlok Aluminum Connector 20012, visit the official 3M website.
Locally owned and operated in Canton, OH, JAM Industrial Supply, LLC has been a 3M Premier distributor and industrial supplier for over 20 years. With our vast network of vendors, we are able to supply the industry’s best products, information, delivery and prices to our customers.
| Pieces Per Case | 3 |
|---|---|
| Unit of Measure | Case |
| Product Id | 7100166928 |
| Part Number | 3MABR-20012 |
| UPC | 00054007133438 |
| Per Case | 3 |
| Weight | 0.961 lbs |
| Make to Order | Yes |
| Brand | Scotchlok™ |
| Inside Diameter | 0.76 in, 19.3 mm |
| Maximum Conductor Size | 185 mm² (Stranded), 400 kcmil (Stranded) |
| Minimum Conductor Size | 185 mm², 400 kcmil |
| Length | 3.75 in, 95.3 mm |
| Barrel Style | Standard Barrel |
| Body Material | Aluminum |
| Case Quantity | 3 |
| Conductor Sizes (Imperial) | 400 kcmil |
| Connector Base Metal | Aluminum |
| Connector Type | Compression Connectors |
| Electrical Connector Type | Compression Connectors |
| For Use With | Aluminum or Copper Conductors |
| Maximum Operating Voltage | 35 Kilovolt |
| Maximum Voltage Rating | 35 kV |
| Outer Diameter (Imperial) | 1.187 in |
| Product Color | Green |
| Product Type | Connector |
| Voltage | 35 kV |
| Dimensions | 4.3 × 3.3 × 3.9 in |
