Strong and flexible, 3M High Temperature Aluminum Foil/Glass Cloth Tape 363L consists of an aluminum foil, glass cloth backing combined with a pressure sensitive silicone adhesive. Ideal for use as a protective wrap for heat sensitive cables and other instruments exposed to movement and vibration. Commonly used in aerospace, automotive and general industrial applications.
Strength with Combined Technology
3M™ High Temperature Aluminum Foil/Glass Cloth Tape 363L is a linered version of the 3M™ High Temperature Aluminum Foil/Glass Cloth Tape 363 and is suitable for die cutting operations. It is strong and flexible tape with high tensile strength, puncture and tear resistance. With a pressure sensitive silicone adhesive, it adheres well to silicone surfaces and over irregular or uneven substrates. This tape is light and heat reflective, plus it resists flame, moisture, weather and UV degradation. It is a chemical resistant, thermally conductive tape that performs consistently at temperatures ranging from -65°F/-54°C to 600°F/316°C.
3M™ High Temperature Aluminum Foil/Glass Cloth Tape 363L meets the requirements of F.A.R. 25.853 (a).
Recommended Applications
For more information about High Temperature Aluminum Foil/Glass Cloth Tape 363L, visit the official 3M website.
| Pieces Per Case | 2 |
|---|---|
| Unit of Measure | Case |
| Product Id | 7010375889 |
| Part Number | 3MABR-363L |
| UPC | 00051115638848 |
| Per Case | 2 |
| Weight | 21.623 lbs |
| Make to Order | Yes |
| Brand | 3M™ |
| Back Side Adhesive Thickness | 0.13 mm, 3.9 mil |
| Backing (Carrier) Thickness | 0.06 mm, 2.4 mil |
| Core Size | 3 in, 7.62 cm |
| Length | 108 yd, 98.75 m |
| Width | 114.3 mm, 4.5 in |
| Tensile Strength | 135 lb/in, 236.4 N/100mm |
| Adhesive Type | Silicone |
| Application | Shielding Wire Harnesses Against Heat |
| Backing (Carrier) Material | Aluminum Foil/Glass Cloth |
| Elongation at Break | 7% |
| Indoor/Outdoor | Indoor/Outdoor |
| Industries | Aerospace, Appliance, Automotive, Construction, Electronics, General Industrial, Metalworking, Military & Government, Specialty Vehicles, Transportation |
| Product Color | Silver |
| Specifications Met | ASTM E-162, ASTM E-662, BSS-7239, FAR 25.853(a) |
| Units per Case | 8 |
| Dimensions | 13.9 × 13.9 × 10 in |
