3M DBI-SALA Smart Lock Self-Retracting Lifeline are the smartest SRLs yet. From reducing nuisance lockups, to simplifying inspections, every detail of the new 3M DBI-SALA Smart Lock Self-Retracting Lifeline is designed with helping workers perform with safety and convenience
Using advanced motion capture technology, 3M studied the forces applied to the SRL during typical at-height tasks. This data helped 3M engineer a new arrest mechanism that can more easily detect the difference between a fall and normal work motion, tailoring a SRL for your work application.
For more information about DBI-SALA Smart Lock Self-Retracting Lifeline 3503878, visit the official 3M website.
| Pieces Per Case | 1 |
|---|---|
| Unit of Measure | Each |
| Product Id | 7100306995 |
| Part Number | 3MABR-3503878 |
| UPC | 00648250239452 |
| Weight | 16.800 lbs |
| Make to Order | Yes |
| Brand | DBI-SALA® |
| Average Arrest Force | 1125 lbf (ANSI), 1125 lbf (OSHA 130 lb – 310 lb), 5 kN (ANSI), 5 kN (OSHA 130 lb – 310 lb) |
| Lifeline Length | 15.2 m, 50 ft |
| Maximum Arrest Force | 1500 lbf (ANSI), 1800 lbf (OSHA up to 420 lb), 6.7 kN (ANSI), 8 kN (OSHA up to 420 lb), 1350 lbf (OSHA 130 lb – 310 lb), 6 kN (OSHA 130 lb – 310 lb) |
| Length | 15.2 m, 50 ft |
| Weight | 16.13 lb, 7.32 kg |
| Weight Capacity | 190 kg, 420 lb |
| Working Length | 14.59, 48 |
| Anchor Connection Type | Carabiner |
| Anchor Hook Material | Zinc Plated Steel |
| Anchor Material | Zinc Plated Steel |
| Case Quantity | 1.0 per Case |
| Connected Safety ID Equipped | Yes |
| Harness Connection Type | Swiveling Snap Hook |
| Housing Material | Glass-Filled Nylon |
| Leg Count | Single-Leg |
| Lifeline Connection Type | Snap Hook |
| Lifeline Hook Material | Zinc Plated Steel |
| Lifeline Material | Galvanized Steel |
| Mounting Type | Overhead Anchor Point |
| Product Series | Smart Lock |
| Product Type | Self-Retracting Lifeline- Cable |
| Recommended Application | Climbing, Inspection, Assembly, Maintenance |
| Recommended Industry | Construction |
| Specifications Met | 29 CFR OSHA 1910.140, ANSI Class Level 1, ANSI/ASSP Z359.14-2021, 29 CFR OSHA 1926.502 |
| Size | 4.750 in X 10.500 in |
| Dimensions | 10.500 × 4.750 × 16.000 in |
