The Adjustable Height 3M DBI-SALA FlexiGuard C-Frame System helps protect workers from falls while providing a large working space. The rigid rail is made from durable extruded aluminum and is rated for use by up to two workers at once. Sitting atop pneumatic wheels, This mobile safety system can be easily moved from one job to the next by manual means or with the assistance of a tow bar and service vehicle.
Each Adjustable Height 3M DBI-SALA FlexiGuard C-Frame System includes one rail made with extruded aluminum. The single rail design is rated to support the weight of two workers in a fall arrest situation. The Adjustable Height system is great for areas without overhead obstructions or door height restrictions. The DBI-SALA FlexiGuard Solutions are designed to be versatile and mobile to help ensure workers’ safety in a variety of challenging conditions. 3M’s pre-engineered systems provide secure anchor points and spacious, safe working areas to help personnel focus on the task at hand while working at heights.
For more information about DBI-SALA FlexiGuard C-Frame System, visit the official 3M website.
| Pieces Per Case | 1 |
|---|---|
| Unit of Measure | Each |
| Product Id | 7100220313 |
| Part Number | 3MABR-8517711 |
| UPC | 00840779006465 |
| Weight | 3800 lbs |
| Make to Order | Yes |
| Brand | DBI-SALA® |
| Maximum Height | 12.08 m, 39.63 ft |
| Net Weight | 1043.3 kg, 2300 lb |
| Width | 15.52 ft, 4.73 m |
| Weight Capacity | 190 kg, 420 lb |
| Case Quantity | 1 |
| Connected Safety ID Equipped | Yes |
| Install Type | Temporary/Portable |
| Maximum Number of Users | Two |
| Product Color | Silver, Yellow |
| Product Series | FlexiGuard™ |
| Product Type | C-Frame System – Adjustable Height |
| Recommended Industry | Transportation, Construction, Mining |
| Specifications Met | OSHA 1926.502 |
| Weight (Imperial) | 2300 lb |
| Size | 87.7 in X 87.7 in |
| Dimensions | 87.7 × 87.7 × 87.7 in |
