3M Highland Vinyl Insulated Butted Seam Male Disconnect offers superior holding force while allowing for quick and easy disconnect. The terminal has a vinyl-insulated, butted-seam barrel and withstands temperatures of -40 to 221 degrees F (-40 to 105 degrees C). Its electrolytic copper construction offers good conductivity and a tin-plated finish resists corrosion.
3M Highland Vinyl Insulated Butted Seam Male Disconnect attaches to the mating part with a tongue that slips over the female tab. It has a butted-seam barrel that is covered by a funnel-designed, rigid-molded, polyvinyl chloride sleeve which serves to guide the wire into position. The polyvinyl chloride sleeve provides electrical contacts and mechanical stress relief at the point of insulation. The vinyl-sleeve insulation is abrasion-resistant and flared to ensure easy crimping. UL Listed, CSA Certified and RoHS 2011/65/EU Compliant.
For more information about Butted Seam Bullet Style Male Disconnect, visit the official 3M website.
Locally owned and operated in Canton, OH, JAM Industrial Supply, LLC has been a 3M Premier distributor and industrial supplier for over 20 years. With our vast network of vendors, we are able to supply the industry’s best products, information, delivery and prices to our customers.
| Pieces Per Case | 1 |
|---|---|
| Product Id | 7100165129 |
| Part Number | 3MABR-82M-180-A |
| UPC | 00051128574126 |
| Weight | 0.002 lbs |
| Make to Order | Yes |
| Brand | 3M™ |
| Connection Width | 0.18 in, 4.572 mm |
| Maximum Conductor Size | 14 AWG, 2.5 mm² |
| Minimum Conductor Size | 16 AWG, 1.5 mm² |
| Disconnect Type | Male |
| Terminal Type | Disconnect |
