Product Description
Advantages of Double Coated Film Tape 9589
- High density polyethylene carrier provides dimensional stability and tears by hand
- Adhesive removes cleanly from many surfaces to ensure a relatively easy clean-up process
- Excellent quick stick and high adhesion ensure a reliable bond to a variety of substrates
- This tape is in compliance with the FDA 21 CFR 175.105 guidelines for indirect food contact
3M™ Double Coated Film Tape 9589 features a high-density polyethylene carrier with synthetic rubber adhesive on a densified kraft paper liner. It combines high initial adhesion and good holding power to ensure it bonds to a variety of materials. 3M specially treats the paper liner to improve its strength and removability characteristics.
Long-Lasting Performance
3M™ Double Coated Film Tape 9589 is a 9.0 mil double coated tape with a high tack synthetic rubber adhesive on a high density polyethylene (HDPE) carrier. 3M™ Adhesive 760 provides excellent quick stick and bonds together a wide variety of materials, with a build-up over 24 hours that allows for proper placement of bonded materials. It features excellent adhesion to both high surface energy and low surface energy substrates. Additionally, it is an excellent choice for many indoor and room temperature applications such as carpet installation. The HDPE carrier adds dimensional stability to aid in removal while also providing easier handling during slitting, lamination and die cutting, and it tears by hand for quick and easy application. The tape is mounted on a 3.7 mil 62 lb. densified kraft paper liner which has been specially treated to improve strength and removability from high internal strength surfaces. This tape can withstand short-term temperatures of up to 200°F.
Recommended Applications
- Carpet installation
- General industrial mounting, joining and splicing
- Miscellaneous joining and holding where jobs require high initial tack
- Die-cutting and laminating applications
Additional information
Weight | 30.0024 lbs |
---|---|
Unit of Measure | |
Product Id | |
Part Number | |
UPC | |
Per Case | |
Size | |
Make to Order | |
Restriction | |
Adhesion To Foam | |
Adhesion To Hse | |
Adhesion To Lse | |
Adhesion To Metal | |
Adhesive Peel Initial | |
Adhesive Peel Ultimate | |
Adhesive Thickness (mils) | |
Adhesive Type | |
Backside Adhesive Thickness (mils) | |
Backside Adhesive Type | |
Carrier Color | |
Carrier Material | |
Carrier Thickness (mils) | |
Chemical Resistance | |
China Rohs Below Mcv | |
Eu Rohs Compliant | |
Faceside Adhseive Thickness (mils) | |
Faceside Adhseive Type | |
Humidty Resistance | |
Liner Color | |
Liner Thickness | |
Liner Type | |
Color | |
Length | |
Thickness | |
Width | |
Master Size Width | |
Maximum Operating Temperature (fahrenheit) | |
Maxmum Operating Temperature (celsius) | |
Minimum Operating Temperature (fahrenheit) | |
Moisture Resistance | |
Nominal Adhesive Thickness (mils) | |
Plasticizer Resistance | |
Primary Liner Thicknes (mils) | |
Secondary Liner | |
Shear Strength At 72 Degrees F | |
Solvent Resistance | |
Tape Thickness | |
Tape Type | |
Total Thickness | |
Uv Resistance |
