Product Description
Advantages of 3M™ Scotchlok™ Male Disconnect MNG14-187DMIX
- Non-insulated, butted-seam barrel ensures a secure fit and offers reliable performance
- Beveled mouth offers easy insertion of wires
- Wider tongue design for use on free-standing studs
- Made of electrolytic copper for good conductivity and has tin plating for corrosion resistance
- Withstands a maximum temperature of 347 degrees F (175 degrees C) for bare terminals
- 600V-rated for building wire and 1000V for signs, fixtures or luminaires
- UL Listed, CSA Certified and RoHS 2011/65/EU Compliant
3M™ Scotchlok™ Male Disconnect MNG14-187DMIX has a wider tongue for use on free-standing studs. The non-insulated, butted-seam barrel has a beveled mouth that guides the wire into position. Electrolytic copper construction offers good conductivity and a tin-plated finish resists corrosion.
3M™ Scotchlok™ Male Disconnect MNG14-187DMIX withstands a maximum temperature of 347 degrees F (175 degrees C). UL Listed, CSA Certified and RoHS 2011/65/EU Compliant.
About JAM Industrial Supply of Ohio
Locally owned and operated in Canton, OH, JAM Industrial Supply, LLC has been a 3M Premier distributor and industrial supplier for over 20 years. With our vast network of vendors, we are able to supply the industry’s best products, information, delivery and prices to our customers.
Additional information
| Weight | 3 lbs |
|---|---|
| Unit of Measure | |
| Per Case | |
| Product Id | |
| Part Number | |
| UPC | |
| Barrel Inside Diameter | 0.145 in |
| Barrel Style | Butted |
| Brand | |
| Color | |
| Connection Width | 0.187 in |
| CSA File Number | LR22190 |
| Diameter | |
| Disconnect Type | Male |
| Fastener Orientation | Male |
| Insulation Color | Blue |
| Insulation Material | Nylon with insulation grip |
| Male Tab Width | 0.187 in |
| Make to Order | |
| Material | |
| Maximum Conductor Size | 14 AWG |
| Minimum Conductor Size | 16 AWG |
| Overall Diameter | 0.3 in |
| Overall Length | |
| Overall Width | 0.37 in |
| Pad Width | 0.187 in |
| Tab Width | 0.25 |
| Terminal Style | Fully insulated |
| Terminal Type | Disconnect |
| UL File Number | E70512 |
| Voltage Application | Low voltage |
