Product Description
Advantages of 3M™ Scotchlok™ Fork MNG10-8FX
- Nylon-insulated, butted-seam barrel ensures a secure fit and offers reliable performance
- Funnel-designed, seamless brass sleeve offers easy insertion of wires
- Wider tongue design for use on free-standing studs
- Electrolytic copper construction offers good conductivity
- Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)
- 600V-rated for building wire and 1000V for signs, fixtures or luminaires
- UL Listed, CSA Certified and RoHS 2011/65/EU Compliant
3M™ Scotchlok™ Fork MNG10-8FX has a wider tongue for use on free-standing studs. The terminal has a nylon-insulated, butted-seam barrel and withstands temperatures of -40 to 221 degrees F (-40 to 105 degrees C). Electrolytic copper construction offers good conductivity and a tin-plated finish resists corrosion.
3M™ Scotchlok™ Fork MNG10-8FX is color-coded for quick and easy identification of the wire size required. The funnel-designed, seamless brass sleeve guides the wire into position while providing electrical contacts and mechanical stress relief at the point of insulation. The abrasion-resistant, flared, nylon-sleeve insulation ensures positive grip and has a stepped design for mistake-proof crimping. UL Listed, CSA Certified and RoHS 2011/65/EU Compliant.
About JAM Industrial Supply of Ohio
Locally owned and operated in Canton, OH, JAM Industrial Supply, LLC has been a 3M Premier distributor and industrial supplier for over 20 years. With our vast network of vendors, we are able to supply the industry’s best products, information, delivery and prices to our customers.
Additional information
| Weight | 3.2 lbs |
|---|---|
| Unit of Measure | |
| Per Case | |
| Product Id | |
| Part Number | |
| UPC | |
| Barrel Inside Diameter | 0.135 in |
| Barrel Style | Butted |
| Brand | |
| Clearance (C) | 0.29 in |
| Color | |
| Dimension E | 0.84 in |
| Fork Type | Standard |
| Insulation Material | Nylon with insulation grip |
| Make to Order | |
| Material | |
| Maximum Conductor Size | 10 AWG |
| Maximum Insulation Outer Diameter | 0.25 in |
| Maximum Operating Temperature | 105 degrees C |
| Maximum Recommended Voltage Rating | 600 V |
| Minimum Conductor Size | 12 AWG |
| Overall Length | |
| Overall Width | 0.38 in |
| Stud Size | #8 |
| Terminal Style | Standard |
| Terminal Type | Fork |
| UL File Number | E23438 |
| Maximum Insulation Outside Diameter | 0.145 in |
