Product Description
Advantages of 3M™ Scotchlok™ Female Disconnect
- Non-insulated, butted-seam barrel ensures a secure fit and offers reliable performance
- Beveled mouth offers easy insertion of wires
- For use in ovens, motors, light fixtures and other applications
- Made of durable steel for high-temperature applications and has nickel plating for corrosion resistance
- Withstands a maximum temperature of 900 degrees F (482 degrees C)
3M™ Scotchlok™ Female Disconnect ensures an ideal fit while offering reliable and safe performance. The terminal has a non-insulated, butted-seam barrel and withstands a maximum temperature of 900 degrees F (482 degrees C). Steel construction offers durability and a nickel-plated finish resists corrosion.
3M™ Scotchlok™ Female Disconnect has a beveled mouth to guide the wire into position easily.
About JAM Industrial Supply of Ohio
Locally owned and operated in Canton, OH, JAM Industrial Supply, LLC has been a 3M Premier distributor and industrial supplier for over 20 years. With our vast network of vendors, we are able to supply the industry’s best products, information, delivery and prices to our customers.
Additional information
| Weight | 3 lbs |
|---|---|
| Unit of Measure | |
| Per Case | |
| Product Id | |
| Part Number | |
| UPC | |
| Barrel Inside Diameter | 0.076 in |
| Barrel Length | 0.25 in |
| Barrel Style | Insulation grip with interlocking barrel |
| Brand | |
| Connection Width | 0.25 in |
| CSA File Number | LR22190 |
| Disconnect Type | Female |
| Fastener Orientation | Female |
| Insulation Material | Nylon with insulation grip |
| Make to Order | |
| Mates with Female Width | 0.25 in |
| Mates with Male Tab Width (W) | 0.25 in |
| Maximum Conductor Size | 18 AWG |
| Maximum Insulation Outer Diameter | 0.145 in |
| Minimum Conductor Size | 22 AWG |
| Overall Length | |
| Pad Width | 0.25 in |
| Tab Witdh | 0.25 |
| Terminal Style | Standard |
| Terminal Type | Disconnect |
| UL File Number | E70512 |
