Product Description
Advantages of 3M™ Highland™ Butt Connector BSV10Q
- Red vinyl-insulated, butted-seam barrel ensures a secure fit and offers reliable performance
- Funnel-designed, polyvinyl chloride sleeve offers easy insertion of wires
- Built-in wire stop for correct positioning
- Accommodates wire sizes 22 to 18 AWG
- Made of electrolytic copper for good conductivity and has tin plating for corrosion resistance
- Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)
- 600V-rated for building wire and 1000V for signs, fixtures or luminaires
- 1000/case
- 25/bag
3M™ Highland™ Butt Connector BSV10Q ensures an ideal fit while offering reliable and safe performance. The connector has a vinyl-insulated, butted-seam barrel and withstands temperatures of -40 to 221 degrees F (-40 to 105 degrees C). The electrolytic copper terminal offers good conductivity and a tin-plated finish resists corrosion.
3M™ Highland™ Butt Connector BSV10Q is color-coded for quick and easy identification of the wire size required. The splice has a butted-seam barrel that is covered by a funnel-designed, rigid-molded, polyvinyl chloride sleeve to guide the wire into position while providing electrical contacts and mechanical stress relief at the point of insulation. The abrasion-resistant, flared, vinyl-sleeve insulation ensures easy crimping. UL Listed, CSA Certified and RoHS 2011/65/EU Compliant.
About JAM Industrial Supply of Ohio
Locally owned and operated in Canton, OH, JAM Industrial Supply, LLC has been a 3M Premier distributor and industrial supplier for over 20 years. With our vast network of vendors, we are able to supply the industry’s best products, information, delivery and prices to our customers.
Additional information
| Weight | 1.5 lbs |
|---|---|
| Unit of Measure | |
| Per Case | |
| Product Id | |
| Part Number | |
| UPC | |
| Barrel Inside Diameter | 0.25 in |
| Barrel Length | 0.25 in |
| Barrel Style | Butted seam |
| Body Material | Copper alloy |
| Brand | |
| Conductor Sizes | 12 – 10 AWG |
| Connector Type | Butt |
| CSA File Number | LR22190 |
| Insulated | Yes |
| Insulation Color | red |
| Insulation Material | Vinyl |
| Material | |
| Max Number of Cores | 409 |
| Maximum Conductor Size | 10 AWG |
| Maximum Insulation Outer Diameter | 2.5 in |
| Maximum Insulation Outside Diameter | 0.145 in |
| Maximum Operating Temperature | 105 degrees C |
| Maximum Recommended Voltage Rating | 600 V |
| Maximum Voltage Rating | 600 V to 1000 V |
| Minimum Conductor Size | 12 AWG |
| Operating Temperature Range (celsius) | |
| Operating Temperature Range (fahrenheit) | |
| Overall Length | |
| Terminal Material | Tin-plated electronic copper |
| Terminal Style | Standard |
| Terminal Type | Butt connector |
| UL File Number | E23438 |
