Product Description
Advantages of 3M™ Double Coated Tape 9576
- Medium tack double coated tape for roll-to-roll splicing, core starting and roll closing
- Excellent peel and shear strength to withstand rigorous splicing applications
- Bonds well to most substrates, including low surface energy plastics
- Excellent UV and heat resistance
- Conformable to irregular surfaces
- Double sided adhesion increases dimensional stability for easy handling
3M™ Double Coated Tape 9576 is a medium tack tape for general splicing and roll closing applications. This tape offers ultra-high peel strength and excellent shear strength for durability. It is conformable to irregular surfaces and offers excellent UV and heat resistance.
Ideal for Rigorous Splicing Applications
3M™ Double Coated Tape 9576 is a 4.0 mil double coated tape with a hand-tearable clear polypropylene carrier lined on both sides with 3M™ Adhesive 400. Once bonded, this tape provides excellent peel and shear strength – making it ideal for rigorous splicing applications and bonding plastics to metals. 3M™ Double Coated Tape 9576 is mounted on a tan 60# densified kraft paper liner for ease in die-cutting applications.
Recommended Applications • Web splicing • Core starting • General purpose bonding
Provides Reliable Performance
The medium-firm pressure sensitive acrylic adhesive system features an excellent balance of good initial adhesion (quick stick) and good shear holding power. The formulation gives a consistently strong bond across a range of temperatures, up to 165°F (75°C). A thin, tough, polypropylene carrier between the adhesive layers improves the handling and strength of the tape. By using a robust 60 lb. densified kraft paper release liner, this tape provides reliable performance for industrial applications, such as die-cutting and automated dispensers.
Understanding Double Coated Tape
In general, double coated tape is composed of a paper, film, or tissue carrier that is coated on both sides with pressure sensitive adhesive. The adhesive is protected by a peel-away liner that can be removed at the time of application or left in place until the joining surfaces are ready to be attached. These tapes can be applied by hand or with a dispenser. Double coated tape dispensers are available in a variety of configurations ranging from manual to fully automatic. Applications for double coated tape are found in construction, fabrication, arts and hobby industries, among others.
About JAM Industrial Supply of Ohio
Locally owned and operated in Canton, OH, JAM Industrial Supply, LLC has been a 3M Premier distributor and industrial supplier for over 20 years. With our vast network of vendors, we are able to supply the industry’s best products, information, delivery and prices to our customers.
Additional information
| Weight | 23.3 lbs |
|---|---|
| Unit of Measure | |
| Per Case | |
| Applications | Zero-speed and general splicing |
| Back Side Adhesive Thickness | 1.5 mil |
| Back Side Adhesive Type | High tack acrylic 400 |
| Backing Material | |
| Backing Thickness | |
| Brand | |
| Carrier Material | |
| Color | |
| Face Side Adhesive Thickness | 1.5 mil |
| Face Side Adhesive Type | High tack acrylic 400 |
| Industries | General industrial |
| Master Size Length | 360 linear yard |
| Master Size Width | |
| Maximum Operating Temperature | 52 degrees C |
| Minimum Operating Temperature | -40 degrees C |
| Overall Length | |
| Overall Thickness | 4 mil |
| Overall Width | 2 in |
| Physical Form | |
| Primary Liner | |
| Primary Liner Color | |
| Primary Liner Thickness | 4 mil |
| Shelf Life | |
| Total Tape Thickness without Liner | 4 mil |
